Pure Copper Electrode

Pure Copper Earthing Electrode
Product Highlights
Material
Pure Copper
Product Type
Copper Electrode
Brand
AP Associate
Diameter
17mm, 20mm, 25mm, 32mm, 50mm, 65mm, 80mm
Size
Custom Size
Surface Treatment
None
Purity
99.99%
Technique
Pipe in Pipe / Pipe in Stripe
Usage/Application
Earthing / Grounding System / Industrial / Residential
Color
Copper
Type
Threaded or Pointed
Model Name/Number
APACU
Operating Temperature
High
ISO Certified
Yes
OEM/ODM Support
Yes (OEM, ODM, OBM)
Warranty
25 Years
Lifespan
More than 50 years
Payment Mode
Online, Cash on Delivery, Cheque
Delivery Time
Same Day Delivery
Get Free Consultation for this Product. Call us at: +91-9643-293-535
Get in Touch with Our Experts!

Know About Pure Copper Electrode

At AP Associate, we manufacture and supply premium Pure Copper Electrode and Pure Copper Earthing Electrode designed to deliver highly efficient and long-lasting earthing solutions for residential, commercial, and industrial applications. Made from 99.9% pure electrolytic copper, our Pure Copper Rods and Solid Copper Electrodes offer unmatched electrical conductivity, exceptional corrosion resistance, and consistent performance for years to come.

A Pure Copper Earthing Electrode plays a vital role in any earthing system by providing a highly conductive, low-resistance path to safely discharge fault currents, lightning strikes, and voltage surges deep into the ground. This protects electrical equipment, structures, and human life from dangerous electrical hazards, ensuring maximum safety and uninterrupted system performance. Our electrodes meet all Pure Copper Earthing Specifications and comply with industry standards, including the relevant Pure Copper Earthing Electrode HSN Code

Our Pure Copper Earthing Electrode are precisely engineered and rigorously tested to meet national and international quality standards. As trusted Pure Copper Earthing Electrode manufacturers in india, we ensure that our electrodes are highly durable, maintenance-free, and suitable for all soil conditions, including areas with high soil resistivity. Due to their superior corrosion resistance, these electrodes, including Pure Copper Chemical Earthing Electrode, offer a significantly longer service life compared to conventional electrodes. We also offer competitive Pure Copper Earthing Electrode price options to fit various project budgets.

At AP Associate, we combine product excellence with expert technical support and personalized customer service. We understand that every site has unique earthing needs, which is why we offer customized solutions to match your specific requirements and ensure complete safety and compliance. Whether you need a Pure Copper Earthing Rod, a Solid Copper Electrode, or technical advice on Pure Copper Earthing Specifications, our team is here to help.

Invest in a robust and reliable grounding system with our trusted Pure Copper Electrode and Pure Copper Earthing Electrode. Contact us today to learn more about our Pure Copper Rods, receive professional guidance, and request a competitive quote. Let us help you build a safer and more secure electrical infrastructure with confidence.

Three types of Electrodes are manufactured by us

Pure Copper earthing electrode: In these type of electrode Pure copper pipe is used to construct these. Pipe in pipe technology – In these types of electrodes both outer and inner pipes are made of pure copper. Strip in Pipe – In these type of electrodes outer pipe is strip are of pure copper.

Copper bonded earthing electrode: In these type of electrodes copper plated pipes are used while strip used is of pure copper.

GI Earthing Electrode: in these type of electrode Pipe and strips are made of galvanized iron.

Pure Copper Earthing Specification

Models Electrode Diameter (MM) Length (MM) Internal Strip Size (MM) Conductive mineral filled
APA40/2Cu
40
2000
25 X 03
Yes
APA40/2Cu
40
2000
25 X 04
Yes
APA40/3Cu
40
3000
25 X 04
Yes
APA50/2Cu
50
2000
30 X 04
Yes
APA50/3Cu
50
3000
30 X 04
Yes
APA75/2Cu
75
2000
50 X 06
Yes
APA75/3Cu
75
3000
50 X 06
Yes

Similar Products

Rating & Reviews

Frequently Asked Questions (FAQs)

What is a Pure Copper Electrode in chemical earthing?
A pure copper electrode is a high-conductivity grounding rod made entirely from electrolytic-grade copper. It offers excellent corrosion resistance and long-term performance in earthing applications.
What are the advantages of using a Pure Copper Electrode?
  • High electrical conductivity
  • Excellent corrosion resistance
  • Long service life (often 20+ years)
  • Stable performance in all soil types
Where is a Pure Copper Electrode used?
Pure copper electrodes are commonly used in sensitive installations such as data centers, hospitals, telecom towers, power plants, and industrial facilities.
What sizes are available in pure copper electrodes?
Available diameters: 12.7 mm, 17 mm, 25 mm, 50 mm, and above Length options: 1 mtr, 2 mtr, 3 mtr (custom lengths available)
What purity level is used in your copper electrodes?
We use 99.9% pure electrolytic copper to ensure maximum conductivity and durability.
What is the typical service life of a pure copper electrode?
20 to 30 years, depending on soil conditions and installation quality.
Is the electrode solid copper or copper bonded?
These are solid copper electrodes, not bonded. For cost-effective options, we also offer copper-bonded steel electrodes.
Can pure copper electrodes be used in rocky or dry soil?
Yes, when used with proper backfill compounds, they perform well in all soil types.
Is any backfill compound required with a pure copper electrode?
Yes, we recommend using a proprietary chemical compound (like bentonite or graphite-based compound) to maintain low resistance and retain moisture.
Does it require regular maintenance?
Minimal maintenance is required. We recommend periodic resistance testing (every 6–12 months) to ensure performance.
How is the pure copper electrode packaged?
Each rod is individually packed with protective wrapping (bubble or foam) to prevent damage during transit.
Do you provide installation support?
Yes, we offer professional on-site installation and testing services.
Is your product certified?
Yes, our pure copper electrodes are tested and certified as per IS:3043 and IEC standards.

Compare with Other Products

Features Pure Copper Electrode Copper Lighting Arrester GI Electrode
Conductivity ⭐️⭐️⭐️⭐️⭐️ ⭐️⭐️⭐️⭐️ ⭐️⭐️⭐️
Lifespan 30+ Years 15–20 Years 10 Years
Corrosion Resistance High High Low
Cost High High Low
